1、Description

FSP-P-16-J Fiber Distribution Box is used as a termination point for the feeder cable to connect with drop cable in FTTx communication network system. The fiber splicing, splitting, and distribution can be done in this box, and meanwhile it provides solid protection and management for the FTTx network building.

2、Specification

1) Water-proof design with IP65 Protection grade.

2) Integrated with splice cassette and cable management system.

3) Manage fibers in a reasonable fiber radius condition.

4) Protection Grade : IP65

5) Fiber bend radius control more than 35mm.

6) One uncut cable port for feeder cables.

3、Applications

1) FTTH access network

2) Telecommunication network

3) CATV networks

4) Data communications network

5) Local area networks

4、Configuration Table

Table 1 Model and configuration
