1. Features
l Low insertion loss and low PDL.
l High reliability and channel counts.
l Uniform power splitting
l Wide wavelength range.
l Excellent environmental stability.
l Customized packaging and configuration.
2. Technical Data：
|
Characteristics |
Values |
|
Model |
FSP-PLC-T |
|
Adaptor type |
SC / LC / FC |
|
Shell Material |
Plastic |
|
Color Of Fiber |
White (Default) |
|
Length Of Fiber |
1M (Customizable ) |
|
1×N(N>2)PLCS(With connector) Optical parameters |
||||||
|
Parameters |
1×2 |
1×4 |
1×8 |
1×16 |
1×32 |
1×64 |
|
Operation wavelength(nm) |
1260~1650 |
|||||
|
Insertion loss(dB) Max |
4.1 |
7.4 |
10.5 |
13.6 |
17.1 |
20.4 |
|
Loss uniformity(dB) Max |
0.4 |
0.5 |
0.6 |
1.0 |
1.3 |
1.9 |
|
Return loss(dB) APC Min |
55 |
55 |
55 |
55 |
55 |
55 |
|
Return loss(dB) UPC Min |
50 |
50 |
50 |
50 |
50 |
50 |
|
PDL(dB) Max |
0.2 |
0.2 |
0.3 |
0.3 |
0.3 |
0.3 |
|
Directivity(dB) Min |
55 |
55 |
55 |
55 |
55 |
55 |
|
Operation temperature(℃) |
-20~65 |
|||||
|
Storage temperature(℃) |
-40~85 |
|||||
|
2×N(N>2)PLCS(With connector) Optical parameters |
||||||
|
Parameters |
2×2 |
2×4 |
2×8 |
2×16 |
2×32 |
2×64 |
|
Operation wavelength(nm) |
1260~1650 |
|||||
|
Insertion loss(dB) Max |
4.4 |
7.7 |
10.8 |
14.1 |
17.4 |
20.7 |
|
Loss uniformity(dB) Max |
0.6 |
1.2 |
1.5 |
1.8 |
2.0 |
2.0 |
|
Return loss(dB) APC Min |
55 |
55 |
55 |
55 |
55 |
55 |
|
Return loss(dB) UPC Min |
50 |
50 |
50 |
50 |
50 |
50 |
|
PDL(dB) Max |
0.2 |
0.2 |
0.3 |
0.4 |
0.4 |
0.4 |
|
Directivity(dB) Min |
55 |
55 |
55 |
55 |
55 |
55 |
|
Operation temperature(℃) |
-20~65 |
|||||
|
Storage temperature(℃) |
-40~85 |
|||||
|
Characteristics |
Values |
|
RoHS compliant |
Yes |
|
REACH compliant |
Yes |
|
UV resistant |
Yes |
|
Free of halogen |
Yes |
