FSP-SMFC-05-SC details
Features:
1. Suitable for FTTx butterfly type cable (both flat and circle shape are available).
2. Low insertion loss.
3. Easy to open and close.
4. Preset fiber and matching-fluid design ensure the performance.
5. Clamping mechanism ensure long-term reliable connection .
6. Compact size, easy to operate, durable.
Configuration Table:
Connection Type
|
SC
|
Polishing Mode
|
APC/UPC/PC
|
Cable Fixing Method
|
Screwing-Up Knob
|
Cable Diameter
|
2×3 mm
|
Insertion Loss
|
≤ 0.3 dB
|
Return Loss
|
≥ 50 dB (UPC / PC)
≥ 55 dB(APC) |
Tensile Strength
|
≥ 30N
|
Operating temperature
|
-40℃ ~ 75℃
|
Storage temperature
|
-40℃ ~ 85℃
|
